UK50D-1 CNC NESTING MACHINE
1.9kw CC spindle+12 knives tool changer
UK50D-1CNC NESTING MACHINE
The heavy -duty high anti twist fuselage structure,special profile and material which is not easy to deform. Straight row for knives exchanges.
Saving you time is our motivation
Our products include: Panel saw, edge banding machine, reciprocating saw series, over-edging machine, CNC Nesting Machine, carving machine series and so forth, which are exported to more than 50 countries and regions, such as Europe, Russia, Southeast Asia, Middle East, North America, Australia. It has established complete sales system (more than 120 dealers). Over yeas of experience in competitions in domestic and overseas markets, our brand has become one of global well-know brand, which offers trustworthy machinery for global customers.
unisunx
Unisunx group company owns 70000 square meters of production scale.
Besides,it has abundant technique strength, full range of testing method and four professional production lines of woodworking machinery.So it can manufacture thousands sets in one month. Our factories locate at Jiaozhou Bay.
The most important highlights at a glance
Syntec/Delta control systems and driving systems
Syntec/Delta control systems and driving systems
Straight row for knives exchanges
Straight row for knives exchanges
Grinding grade high accuracy gear transmission system,parallelism less than 0.1mm
Grinding grade high accuracy gear transmission system,parallelism less than 0.1mm
UK50D-1CNC NESTING MACHINE
- The heavy -duty high anti twist fuselage structure,special profile and material which is not easy to deform.
- Straight row for knives exchanges.
Details
Technology Data
Model name | UK50D-1 |
Working size (X×Y×Z) | 1220×2800×200mm |
Spindle motor power | 9KW |
Tool changer | 12 knives |
Spindle speed | 0-24000rpm/min |
Control/Driving system | Syntec/Delta |
Vacuum table | 7.5kw |
Overall dimensions | 4200×2400×2400mm |
Net weight | 2800kgs |
