UK50DZT CNC Nesting Machine
9kw CC Spindle +Drilling Packages
UK50DZT CNC Nesting Machine
Saving you time is our motivation
Our products include: Panel saw, edge banding machine, reciprocating saw series, over-edging machine, CNC Nesting Machine(CNC Wood Cutting Machine), carving machine series and so forth, which are exported to more than 50 countries and regions, such as Europe, Russia, Southeast Asia, Middle East, North America, Australia. It has established complete sales system (more than 120 dealers). Over yeas of experience in competitions in domestic and overseas markets, our brand has become one of global well-know brand, which offers trustworthy machinery for global customers.
unisunx
Unisunx group company owns 70000 square meters of production scale.
Besides,it has abundant technique strength, full range of testing method and four professional production lines of woodworking machinery.So it can manufacture thousands sets in one month. Our factories locate at Jiaozhou Bay.
The most important highlights at a glance
1.9kw CC spindle +Drilling packages
1.9kw CC spindle +Drilling packages
Syntec/Delta control systems and driving systems
Syntec/Delta control systems and driving systems
Loading and unloading system
Loading and unloading system
UK50DZT CNC Nesting Machine
- Automatic loading and unloading connection,automatic labeling,improve efficiency
- Servo motor accelerations7ms,repeated positioning 0.03m
- Machining accuracy comparable to that of metal CNC,the diagonal less than 0.1mm
- Grinding grade transmission system,the parallelism less than 0.1mm
- The heavy -duty high anti twist fuselage structure,special profile and material which is not easy
Details
Technology Data
Model name | UK50DZT |
Working size (X×Y×Z) | 1220×2800×200mm |
Spindle motor power | 1×9KW spindle +drilling package |
Tool changer | 12 knives |
Spindle speed | 0-24000rpm/min |
Control/Driving system | Syntec/Delta |
Vacuum table | 7.5kw |
Overall dimensions | 10300×2300×2400mm |
Net weight | 3200kgs |
